Nissan SR20DET [PRE VCT] 2.0L exploded view poster
Nissan SR20DET [PRE VCT] 2.0L exploded view poster
Couldn't load pickup availability
⭐4.6 Star From 190+ Verified Reviews
✅Technically Accurate (or we'll replace it for free)
🔍Fantastic Display Quality
Laser engraved exploded view of Nissan's Iconic SR20DET Engine. Wrapped in a sturdy frame with solid mounting points. Each poster is hand made and laser engraved right here in Adelaide.
Important Buyers Note: This engine is the SR20DET before the introduction of Variable Cam Timing (VCT) in 1995. Please see below the applicable cars that used this engine. To see the later model of the SR20DET with VCT (used in the S14 and S15 etc), Click here.
Important Buyers Note: there are x2 types of intakes used on the SR20DET [Pre VCT version] as far as I understand. This one uses the intake from the S13 Silvia. However, there is another design available using the intake as seen on the Pulsar GTI-R which you can find here.
Applicable cars
1989 Nissan U12 Bluebird
1991 - 1995 Nissan U13 Bluebird
1991 - 1998 Nissan 180SX
1991 - 1998 Nissan Silvia S13
1995 - 1997 Nissan W10 Avenir Salut
1997 - 2001 Nissan W11 Avenir GT4
1990 - 1994 Nissan RNN14 Pulsar GTI-R
1990 - 1995 Nissan EGNN14 Sunny GTI-R
